Eric Beyne - imec

VP R&D / Program Director 3D System Integration Program / Senior Fellow - imec


“2.5D” Chiplet and 3D-SOC integration: heterogeneous technology system scaling
As electronic systems become more complex and CMOS scaling becomes more specialized, the traditional monolithic single-chip system integration gives way to a multi-die heterogenous integration technology. Two main directions can be observed “chiplet” and the “3D-SOC” approach. The “chiplet” approach brings together die that are independently designed and fabricated but share a standardized interface protocol to realize the desired combined function. The “3D-SOC” approach builds upon the highly successful system-on-chip (SOC) design methodology but allows for different parts of the system to be fabricated using different technologies, stacked in multiple layers but co-designed without the addition of additional interface circuitry. To realize 2.5D chiplets or 3D-SOC, a broad range of interconnect technologies are required. This requires a hierarchical 3D-interconnect view, defining a 3D interconnect technology landscape, which extends from the package level all the way to the transistor level, spanning eight orders of magnitude in 3D interconnect density.  This landscape is highly dynamic, as each technology has its own roadmap and scaling roadmap. This presentation will cover imec’s vision and contributions to 3D interconnect scaling.
